CST Ablaze Rear CS02R AT20x11-10 (R)
Sand riders rejoice! The Ablaze has a two ply construction designed to
keep the weight to a minimum while offering the durability needed for
serious dune riding. The rear tire contains offset directional V-style
paddles for improved handling and control while the front tire’s dual
center ribs are created to hold tight in the corners. The front and rear
Ablaze contain a convex profile giving them a balloon effect to keep
your quad floating on top of the sand.
Tire
Size |
- |
AT20x11-10 (R) |
RS (in) |
- |
10x9.0 |
PR |
- |
2 |
OD (mm/in) |
- |
540/21.3 |
SW (mm/in) |
- |
252/9.9 |
Tire Pressure (kpa/psi) |
- |
25/4 |
Max Load (kg/lbs) |
- |
106/233 |
TD (mm/in) |
- |
30.0/1.18 |
- RS = Rim size (diameter x width)
- PR/LSR = Ply rating or Load/Speed Rating
- OD = Overall diameter
- SW = Section width
- Max Load = Maximum load
- TD = Tread depth
Model and size availability may be limited by market.
